Sprayer Comparison
|
|
|
|
|
|---|---|---|---|---|
| Engine | 20HP Honda or Kohler | Tier 4 Final 48HP Diesel Engine | Tier 4 Final 68HP Diesel | Tier 4 Final 70HP Diesel |
| Top Speed | 8MPH | 11MPH | 12MPH | 14MPH |
| Row Width | Manually Adjustable 60in. - 90in. | Manually Adjustable 60in. - 90in. | Hydraulically Adjustable 72in. - 120in. | Hydraulically Adjustable 72in. - 120in. |
| Underframe Clearance | Manually Adjustable 36in. - 66in. | Manually Adjustable 42in. - 72in. | Hydraulically Adjustable 54in. - 78in. | Hydraulically Adjustable 59in. - 84in. |
| Dry Weight | 2700lb. | 3300lb. | 7800lb. | 9800lb. |
| Turning Radius | Articulating Frame 90in. minimum turning radius. | Articulating Frame 90in. minimum turning radius. | Articulating Frame 96in. minimum turning radius | Articulating Frame 150in. minimum turning radius |
| Tire & Wheel | 7.60in. x 15in. Cleated tire with modular wheel | Standard: 7.5in. x 20in. Optional: 7.2in. x 30in. | Standard: 7.2in. x 30in. Optional: 9.5in. x 32in. | 9.5in. x 32in. Tire and Wheel |
| Rider Station | Open with shade canopy, adjustable seat, and seatbelt. | Open with shade canopy, adjustable seat, and seatbelt. | Open-air or optional enclosed cab with A/C and filtration. | Luxury cab with heating, cooling & air suspension seat. |
| Solution Tank | 110gal. | Optional up to 150gal. | Optional up to 250gal. | Optional up to 300gal. |
| Solution Pump | Optional 12v 5.3 GPM / 60 PSI. | Optional Hydraulic Centrifugal/Piston Pump. | Optional Hydraulic Centrifugal/Piston Pump. | Optional Hydraulic Centrifugal/Piston Pump. |
| Brake System | Dynamic: Hydrostatic Static: Hydraulic circuit lock. | Dynamic: Hydrostatic Static: Spring-applied hydraulic released wet disc. | Dynamic: Hydrostatic Static: Spring-applied | Dynamic: Hydrostatic Static: Spring-applied |
| Steering | Side steering wheel. | Center steering wheel. | Center steering wheel. | Center steering wheel. |
| Speed Control | Manual/Foot Shift | Manual/Side Shift or optional Foot Shift | Manual hydrostatic. Optional cab with Canbus controls. | Electronic GPS |
| Running Lights | None. | Amber/red rear lights. | Amber/red rear lights. | Amber/red rear lights. |
| Work Lights | None. | Wide Angle LED Work Lights with directional boom lighting. | Wide Angle LED work lights with directional boom lighting. | Wide Angle LED Work Lights with directional boom lighting. |
| Fuel Tank Capacity | 12gal. | 14gal. | 20gal. | 21gal. |
| Hydraulic Reservoir Capacity | 13.5gal. | 20gal. | 24gal. | 24gal. |
| Aux. Hydraulic Flow | Optional | Optional | 20GPM@3000 PSI | 35GPM@3000 PSI |
| Wheel Base | 85in. | 85in. | 96in. | 115in. |
| Machine Width | 90in. | 90in. | 101in. | 101in. |
| Machine Height | 94in. (Lowest position) | 100in. (Lowest position) | 113in. (Lowest position) | 137in. (Lowest position) |
Configure Your LEE Sprayer Today!
Contact our sales team for any questions or additional information.
